Americandrillbushing(ADB)（美国）
美国钻孔套销公司（American Drill Bushing，ADB）是起重行业的先驱者，以创新和安全的吊环产品和吊装解决方案而闻名。自1943年起，ADB以可靠性为基准，提供多样化的标准和定制吊环，满足行业和政府标准。他们致力于安全、精准工程和准时交付，因此在航空航天、国防、制造业、建筑等多个领域成为首选。ADB对安全的承诺和专业解决方案为其赢得了客户的信任。
| Part No. | Rated Load (lbs) | A | B | C | D | E +/- .12 | F | G | H | J | K | L | M | TL* (ft-lbs) | Weight |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 23050 | 550 | .43 | 1.61 | .71 | 3/8 | .54 | 2.67 | 1/4-20 | 1.84 | 1.00 | .75 | .17 | 1.33 | 5 | 5 oz |
| 23051 | 800 | .43 | 1.61 | .71 | 3/8 | .29 | 2.67 | 5/16-18 | 1.84 | 1.00 | .75 | .17 | 1.27 | 7 | 5 oz |
| 23052 | 800 | .43 | 1.61 | .71 | 3/8 | .54 | 2.67 | 5/16-18 | 1.84 | 1.00 | .75 | .17 | 1.27 | 7 | 5 oz |
| 23053 | 1000 | .43 | 1.61 | .71 | 3/8 | .54 | 2.67 | 3/8-16 | 1.84 | 1.00 | .75 | .17 | 1.21 | 12 | 5 oz |
| 23301 | 2500 | .70 | 2.40 | .93 | 1/2 | 1.07 | 3.77 | 1/2-13 | 2.58 | 1.49 | 1.25 | .20 | 1.84 | 28 | 1 lb |
| 23004 | 2500 | .88 | 3.25 | 1.22 | 3/4 | .78 | 4.78 | 1/2-13 | 3.52 | 1.99 | 1.50 | .16 | 2.31 | 28 | 2 lb. 5 oz |
| •23322 | 2500 | .88 | 3.25 | 1.22 | 3/4 | .78 | 6.72 | 1/2-13 | 3.52 | 1.99 | 1.50 | .16 | 4.25 | 28 | 2 lb. 12 oz |
| 23005 | 2500 | .88 | 3.25 | 1.22 | 3/4 | 1.03 | 4.78 | 1/2-13 | 3.52 | 1.99 | 1.50 | .16 | 2.31 | 28 | 2 lb. 5 oz |
| •23323 | 2500 | .88 | 3.25 | 1.22 | 3/4 | 1.03 | 6.72 | 1/2-13 | 3.52 | 1.99 | 1.50 | .16 | 4.25 | 28 | 2 lb |
| 23006 | 2500 | .88 | 3.25 | 1.22 | 3/4 | 1.28 | 4.78 | 1/2-13 | 3.52 | 1.99 | 1.50 | .16 | 2.31 | 28 | 2 lb. 5 oz |
| •23324 | 2500 | .88 | 3.25 | 1.22 | 3/4 | 1.28 | 6.72 | 1/2-13 | 3.52 | 1.99 | 1.50 | .16 | 4.25 | 28 | 2 lb. 12 oz |
| 23001 | 4000 | .88 | 3.25 | 1.22 | 3/4 | .78 | 4.78 | 5/8-11 | 3.52 | 1.99 | 1.50 | .16 | 2.18 | 60 | 2 lb. 7 oz |
| •23319 | 4000 | .88 | 3.25 | 1.22 | 3/4 | .78 | 6.72 | 5/8-11 | 3.52 | 1.99 | 1.50 | .16 | 4.12 | 60 | 2 lb. 12 oz |
| 23002 | 4000 | .88 | 3.25 | 1.22 | 3/4 | 1.03 | 4.78 | 5/8-11 | 3.52 | 1.99 | 1.50 | .16 | 2.18 | 60 | 2 lb. 7 oz |
| •23320 | 4000 | .88 | 3.25 | 1.22 | 3/4 | 1.03 | 6.72 | 5/8-11 | 3.52 | 1.99 | 1.50 | .16 | 4.12 | 60 | 2 lb. 14 oz |
| 23003 | 4000 | .88 | 3.25 | 1.22 | 3/4 | 1.28 | 4.78 | 5/8-11 | 3.52 | 1.99 | 1.50 | .16 | 2.18 | 60 | 2 lb. 9 oz |
| •23321 | 4000 | .88 | 3.25 | 1.22 | 3/4 | 1.28 | 6.72 | 5/8-11 | 3.52 | 1.99 | 1.50 | .16 | 4.12 | 60 | 3 lb |
| 23007 | 5000 | .88 | 3.25 | 1.22 | 3/4 | 1.03 | 4.78 | 3/4-10 | 3.52 | 1.99 | 1.50 | .16 | 2.06 | 100 | 2 lb 9 oz |
| •23325 | 5000 | .88 | 3.25 | 1.22 | 3/4 | 1.03 | 6.72 | 3/4-10 | 3.52 | 1.99 | 1.50 | .16 | 4.00 | 100 | 3 lb |
| 23008 | 5000 | .88 | 3.25 | 1.22 | 3/4 | 1.28 | 4.78 | 3/4-10 | 3.52 | 1.99 | 1.50 | .16 | 2.06 | 100 | 2 lb. 8 oz |
| 23326 | 5000 | .88 | 3.25 | 1.22 | 3/4 | 1.28 | 6.72 | 3/4-10 | 3.52 | 1.99 | 1.50 | .16 | 4.00 | 100 | 3 lb. 1oz |
| 23009 | 5000 | .88 | 3.25 | 1.22 | 3/4 | 1.53 | 4.78 | 3/4-10 | 3.52 | 1.99 | 1.50 | .16 | 2.06 | 100 | 2 lb. 4 oz |
| •23327 | 5000 | .88 | 3.25 | 1.22 | 3/4 | 1.53 | 6.72 | 3/4-10 | 3.52 | 1.99 | 1.50 | .16 | 4.00 | 100 | 7 lb. 4 oz |
| 23102 | 7000^ | 1.40 | 4.80 | 1.71 | 1″ | 1.04 | 6.52 | 3/4-10 | 5.14 | 3.00 | 2.37 | .24 | 3.06 | 100 | 6 lb. 10 oz |
| •23329 | 7000^ | 1.40 | 4.80 | 1.71 | 1″ | 1.04 | 8.11 | 3/4-10 | 5.14 | 3.00 | 2.37 | .24 | 4.65 | 100 | 6 lb. 10 oz |
| 23103 | 7000^ | 1.40 | 4.80 | 1.71 | 1″ | 1.54 | 6.52 | 3/4-10 | 5.14 | 3.00 | 2.37 | .24 | 3.06 | 100 | 6 lb. 12 oz |
| •23330 | 7000^ | 1.40 | 4.80 | 1.71 | 1″ | 1.54 | 8.11 | 3/4-10 | 5.14 | 3.00 | 2.37 | .24 | 4.65 | 100 | 6 lb. 12 oz |
| 23101 | 8000 | 1.40 | 4.80 | 1.71 | 1″ | 1.04 | 6.52 | 7/8-9 | 5.14 | 3.00 | 2.37 | .24 | 2.93 | 160 | 7 lb |
| •23328 | 8000 | 1.40 | 4.80 | 1.71 | 1″ | 1.04 | 8.11 | 7/8-9 | 5.14 | 3.00 | 2.37 | .24 | 4.52 | 160 | 7 lb |
| 23105 | 10000 | 1.40 | 4.80 | 1.71 | 1″ | 1.29 | 6.52 | 1″-8 | 5.14 | 3.00 | 2.37 | .24 | 2.81 | 230 | 7 lb |
| •23331 | 10000 | 1.40 | 4.80 | 1.71 | 1″ | 1.29 | 8.11 | 1″-8 | 5.14 | 3.00 | 2.37 | .24 | 4.40 | 230 | 7 lb |
| 23106 | 10000 | 1.40 | 4.80 | 1.71 | 1″ | 1.54 | 6.52 | 1″-8 | 5.14 | 3.00 | 2.37 | .24 | 2.81 | 230 | 7 lb |
| •23332 | 10000 | 1.40 | 4.80 | 1.71 | 1″ | 1.54 | 8.11 | 1″-8 | 5.14 | 3.00 | 2.37 | .24 | 4.40 | 230 | 7 lb |
| 23107 | 10000 | 1.40 | 4.80 | 1.71 | 1″ | 2.29 | 6.52 | 1″-8 | 5.14 | 3.00 | 2.37 | .24 | 2.81 | 230 | 7 lb |
| •23333 | 10000 | 1.40 | 4.80 | 1.71 | 1″ | 2.29 | 8.11 | 1″-8 | 5.14 | 3.00 | 2.37 | .24 | 4.40 | 230 | 7 lb |
| 23108 | 10000 | 1.40 | 4.80 | 1.71 | 1″ | 2.29 | 6.52 | 1 1/8″-8 | 5.14 | 3.00 | 2.37 | .24 | 2.81 | 230 | 7 lb |
| 23402 | 15000 | 1.75 | 6.00 | 2.11 | 1.25″ | 1.89 | 8.73 | 1 1/4″-8 | 6.50 | 3.76 | 3.20 | .35 | 4.12 | 470 | 14 lb |
| 23401 | 15000 | 1.75 | 6.00 | 2.11 | 1-1/4 | 1.89 | 8.73 | 1 1/4″-7 | 6.50 | 3.76 | 3.20 | .35 | 4.12 | 470 | 14 lb |
| 23204 | 24000 | 2.25 | 8.00 | 2.81 | 1.75″ | 2.70 | 12.47 | 1 1/2″-8 | 8.55 | 4.87 | 4.20 | .47 | 6.41 | 800 | 33 lb 12 oz |
| 23202 | 24000 | 2.25 | 8.00 | 2.81 | 1-3/4 | 2.70 | 12.47 | 1 1/2″-6 | 8.55 | 4.87 | 4.20 | .47 | 6.41 | 800 | 33 lb. 12 oz |
| 23203 | 30000 | 2.25 | 8.00 | 2.81 | 1-3/4 | 2.96 | 12.47 | 2″-8 | 8.55 | 4.87 | 4.20 | .47 | 6.41 | 1100 | 36 lb |
| 23200 | 30000 | 2.25 | 8.00 | 2.81 | 1-3/4 | 2.96 | 12.47 | 2″-4 1/2 | 8.55 | 4.87 | 4.20 | .47 | 6.41 | 1100 | 36 lb |
| 23201 | 30000 | 2.25 | 8.00 | 2.81 | 1-3/4 | 2.96 | 12.47 | 2″-4 1/2 | 8.55 | 4.87 | 4.20 | .47 | 6.41 | 1100 | 36 lb |
| 23501 | 50000 | 3.00 | 10.50 | 4.09 | 2-1/4 | 4.00 | 16.87 | 2 1/2″-8 | 11.67 | 6.52 | 5.75 | 1.12 | 8.03 | 2100 | 87 lb. 8 oz |
| 23503 | 50000 | 3.00 | 10.50 | 4.09 | 2-1/4 | 4.00 | 16.87 | 2 1/2″-4 | 11.67 | 6.52 | 5.75 | 1.12 | 8.03 | 2100 | 87 lb. 8 oz |
| 23600 | 75000 | 3.75 | 13.00 | 5.27 | 2-3/4 | 5.20 | 19.50 | 3″-4 | 14.15 | 8.10 | 7.25 | 1.00 | 8.48 | 4300 | 166 lb |
| 23701 | 100000 | 4.00 | 14.50 | 6.06 | 3-1/4 | 7.00 | 22.09 | 3 1/2″-4 | 15.90 | 8.60 | 7.25 | 1.09 | 9.28 | 6600 | 240 lb |
| 23751 | 150000 | 5.00 | 18.00 | 7.50 | 4.00 | 8.50 | 27.38 | 4 1/4″-4 | 19.69 | 10.75 | 9.87 | 1.33 | 12.13 | 12000 | 525 lb |
| 23760 | 200000 | 6.00 | 22.00 | 9.00 | 5.00 | 9.00 | 33.00 | 5″-4 | 24.00 | 13.00 | 12.38 | 1.88 | 14.50 | 19800 | 760 lb |
| 23770 | 250000 | 6.00 | 22.00 | 9.00 | 5.00 | 9.00 | 33.00 | 6″-4 | 24.00 | 13.00 | 12.38 | 1.88 | 14.00 | 29000 | 841 lb |
| Flip-Flop Hoist Rings | ||||||||||||
|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Part No. with Screws | Rated Load (lbs) | A | B | C | D | E | F | G | H | R | Installation Torque (ft-lbs) | Weight w/ Screws (lbs) |
| 34030S | 2000 | 2″ | 1-3/4 | 1″ | 5/16 | 2-1/2 | 3/4 | 5/16 (2 PLCS) | 0 | 1/2 | 4-7 | .58 |
| 34035S | 2500 | 2-1/2 | 2-1/4 | 1-1/8 | 3/8 | 3-3/16 | 7/8 | 3/8 (2 PLCS) | 0 | 5/8 | 7-10 | 1.07 |
| 34040S | 5000 | 3″ | 2-5/8 | 1-1/2 | 1/2 | 3-7/8 | 1-1/8 | 1/2 (2 PLCS) | 0 | 3/4 | 20-25 | 2.06 |
| 34045S | 12000 | 4″ | 3-1/8 | 1-5/8 | 3/4 | 5-1/4 | 1-3/8 | 1/2 (4 PLCS) | 1-1/4 | 7/8 | 20-25 | 4.10 |
| 34050S | 20000 | 5″ | 3-5/8 | 2-1/16 | 1 | 6-3/16 | 1-7/8 | 5/8 (4 PLCS) | 1-1/4 | 1 | 42-50 | 7.94 |
| Flip-Flop Mounting Screws | ||||
|---|---|---|---|---|
| Part No. | Used P/N | Screw Thread | Screw Length | Weight (lbs) |
| 23812 | 34030S | 5/16-18 | 1 1/4 | .04 |
| 23813 | 34035S | 3/8-16 | 1 1/4 | .05 |
| 23804 | 34040S | 1/2-13 | 2 | .14 |
| 23805 | 34045S | 1/2-13 | 2 1/4 | .16 |
| 33645 | 34050S | 5/8-11 | 2 3/4 | .50 |
| Part No. | Rated Load (lbs) | A | B | C | D | E +/- .12 | F | G | K | L | M | TL (ft-lbs) | Weight (lbs) |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| 33112 | 550 | .65 | 2.29 | .96 | .44 | .56 | 3.23 | 1/4-20 | 1.25 | 0.15 | 1.57 | 5 | .50 |
| 33212 | 800 | .65 | 2.29 | .96 | .44 | .56 | 3.23 | 5/16-18 | 1.25 | 0.15 | 1.51 | 7 | .52 |
| 33213 | 800 | .65 | 2.29 | .96 | .44 | .56 | 3.23 | 5/16-24 | 1.25 | 0.15 | 1.51 | 7 | .52 |
| 33214 | 800 | .65 | 2.29 | .96 | .44 | 1.06 | 3.23 | 5/16-18 | 1.25 | 0.15 | 1.51 | 7 | .54 |
| 33312 | 1000 | .65 | 2.29 | .96 | .44 | .56 | 3.23 | 3/8-16 | 1.25 | 0.15 | 1.45 | 12 | .56 |
| 33313 | 1000 | .65 | 2.29 | .96 | .44 | .56 | 3.23 | 3/8-24 | 1.25 | 0.15 | 1.45 | 12 | .56 |
| 33314 | 1000 | .65 | 2.29 | .96 | .44 | 1.06 | 3.23 | 3/8-16 | 1.25 | 0.15 | 1.45 | 12 | .58 |
| 33316 | 2250 | .65 | 2.29 | .96 | .44 | 1.06 | 3.23 | 1/2-13 | 1.25 | 0.15 | 1.45 | 26 | .60 |
| 33317 | 2250 | .65 | 2.29 | .96 | .44 | 1.06 | 3.23 | 1/2-20 | 1.25 | 0.15 | 1.45 | 26 | .60 |
| 33512 | 2500 | 1.00 | 3.50 | 1.50 | .75 | .75 | 5.31 | 1/2-13 | 1.89 | 0.17 | 2.56 | 28 | 1.71 |
| •33513 | 2500 | 1.00 | 3.50 | 1.50 | .75 | .75 | 6.87 | 1/2-13 | 1.89 | 0.17 | 4.12 | 28 | 2.04 |
| 33515 | 2500 | 1.00 | 3.50 | 1.50 | .75 | 1.00 | 5.31 | 1/2-13 | 1.89 | 0.17 | 2.56 | 28 | 1.72 |
| •33505 | 2500 | 1.00 | 3.50 | 1.50 | .75 | 1.00 | 6.87 | 1/2-13 | 1.89 | 0.17 | 4.12 | 28 | 2.05 |
| 33516 | 2500 | 1.00 | 3.50 | 1.50 | .75 | 1.25 | 5.31 | 1/2-13 | 1.89 | 0.17 | 2.56 | 28 | 1.82 |
| •33517 | 2500 | 1.00 | 3.50 | 1.50 | .75 | 1.25 | 6.87 | 1/2-13 | 1.89 | 0.17 | 4.12 | 28 | 2.15 |
| 33612 | 4000 | 1.00 | 3.50 | 1.50 | .75 | .75 | 5.31 | 5/8-11 | 1.89 | 0.17 | 2.44 | 60 | 1.76 |
| •33613 | 4000 | 1.00 | 3.50 | 1.50 | .75 | .75 | 6.87 | 5/8-11 | 1.89 | 0.17 | 4 | 60 | 2.09 |
| 33614 | 4000 | 1.00 | 3.50 | 1.50 | .75 | 1.00 | 5.31 | 5/8-11 | 1.89 | 0.17 | 2.44 | 60 | 1.78 |
| •33604 | 4000 | 1.00 | 3.50 | 1.50 | .75 | 1.00 | 6.87 | 5/8-11 | 1.89 | 0.17 | 4 | 60 | 2.11 |
| 33615 | 4000 | 1.00 | 3.50 | 1.50 | .75 | 1.25 | 5.31 | 5/8-11 | 1.89 | 0.17 | 2.44 | 60 | 1.88 |
| •33616 | 4000 | 1.00 | 3.50 | 1.50 | .75 | 1.25 | 6.87 | 5/8-11 | 1.89 | 0.17 | 4 | 60 | 2.21 |
| 33714 | 5000 | 1.00 | 3.50 | 1.50 | .75 | 1.00 | 5.31 | 3/4-10 | 1.89 | 0.17 | 2.31 | 100 | 1.89 |
| •33715 | 5000 | 1.00 | 3.50 | 1.50 | .75 | 1.00 | 6.87 | 3/4-10 | 1.89 | 0.17 | 3.87 | 100 | 2.22 |
| 33716 | 5000 | 1.00 | 3.50 | 1.50 | .75 | 1.50 | 5.31 | 3/4-10 | 1.89 | 0.17 | 2.31 | 100 | 2.02 |
| •33717 | 5000 | 1.00 | 3.50 | 1.50 | .75 | 1.50 | 6.87 | 3/4-10 | 1.89 | 0.17 | 3.87 | 100 | 2.35 |
| 33110 | 6300 | 1.50 | 5.10 | 2.05 | 1.00 | 1.20 | 7.37 | 3/4-10 | 2.81 | 0.18 | 3.57 | 100 | 7.23 |
| 33108 | 7000^ | 1.50 | 5.10 | 2.05 | 1.00 | .95 | 7.37 | 3/4-10 | 2.81 | 0.18 | 3.57 | 100 | 7.20 |
| •33168 | 7000^ | 1.50 | 5.10 | 2.05 | 1.00 | .95 | 9.00 | 3/4-10 | 2.81 | 0.18 | 5.20 | 100 | 7.93 |
| 33102 | 7000^ | 1.50 | 5.10 | 2.05 | 1.00 | .1.20 | 7.37 | 3/4-10 | 2.81 | 0.18 | 3.57 | 100 | 7.23 |
| •33162 | 7000^ | 1.50 | 5.10 | 2.05 | 1.00 | .1.20 | 9.00 | 3/4-10 | 2.81 | 0.18 | 5.20 | 100 | 7.96 |
| 33103 | 7000^ | 1.50 | 5.10 | 2.05 | 1.00 | 1.45 | 7.37 | 3/4-10 | 2.81 | 0.18 | 3.57 | 100 | 7.25 |
| •33163 | 7000^ | 1.50 | 5.10 | 2.05 | 1.00 | 1.45 | 9.00 | 3/4-10 | 2.81 | 0.18 | 5.20 | 100 | 7.98 |
| 33104 | 8000 | 1.50 | 5.10 | 2.05 | 1.00 | .95 | 7.37 | 7/8-9 | 2.81 | 0.18 | 3.32 | 160 | 7.33 |
| •33164 | 8000 | 1.50 | 5.10 | 2.05 | 1.00 | .95 | 9.00 | 7/8-9 | 2.81 | 0.18 | 4.95 | 160 | 8.06 |
| 33101 | 8000 | 1.50 | 5.10 | 2.05 | 1.00 | 1.20 | 7.37 | 7/8-9 | 2.81 | 0.18 | 3.32 | 160 | 7.33 |
| •33161 | 8000 | 1.50 | 5.10 | 2.05 | 1.00 | 1.20 | 9.00 | 7/8-9 | 2.81 | 0.18 | 4.82 | 160 | 8.06 |
| 33109 | 8000 | 1.50 | 5.10 | 2.05 | 1.00 | 1.45 | 7.37 | 7/8-9 | 2.81 | 0.18 | 3.32 | 160 | 7.33 |
| •33169 | 8000 | 1.50 | 5.10 | 2.05 | 1.00 | 1.45 | 9.00 | 7/8-9 | 2.81 | 0.18 | 4.82 | 160 | 8.06 |
| 33105 | 10000 | 1.50 | 5.10 | 2.05 | 1.00 | 1.45 | 7.37 | 1″-8 | 2.81 | 0.18 | 3.20 | 230 | 7.57 |
| •33165 | 10000 | 1.50 | 5.10 | 2.05 | 1.00 | 1.45 | 9.00 | 1″-8 | 2.81 | 0.18 | 4.82 | 230 | 8.30 |
| 33106 | 10000 | 1.50 | 5.10 | 2.05 | 1.00 | 1.20 | 7.37 | 1″-8 | 2.81 | 0.18 | 3.20 | 230 | 7.63 |
| •33166 | 10000 | 1.50 | 5.10 | 2.05 | 1.00 | 1.20 | 9.00 | 1″-8 | 2.81 | 0.18 | 4.82 | 230 | 8.36 |
| 33107 | 10000 | 1.50 | 5.10 | 2.05 | 1.00 | 2.20 | 7.37 | 1″-8 | 2.81 | 0.18 | 3.20 | 230 | 7.81 |
| •33167 | 10000 | 1.50 | 5.10 | 2.05 | 1.00 | 2.20 | 9.00 | 1″-8 | 2.81 | 0.18 | 4.82 | 230 | 8.54 |
| 33402 | 15000 | 2.00 | 6.75 | 2.89 | 1.25 | 1.88 | 9.22 | 1 1/4″-7 | 3.75 | 0.40 | 3.76 | 470 | 15.7 |
| 33401 | 15000 | 2.00 | 6.75 | 2.89 | 1.25 | 2.63 | 9.22 | 1 1/4″-7 | 3.75 | 0.40 | 3.76 | 470 | 16.0 |
| 33420 | 20000 | 2.00 | 6.75 | 2.89 | 1.25 | 2.63 | 9.22 | 1 3/8″-6 | 3.75 | 0.40 | 3.64 | 670 | 17.2 |
| 33424 | 24000 | 2.00 | 6.75 | 2.89 | 1.25 | 2.63 | 9.22 | 1 1/2″-6 | 3.75 | 0.40 | 3.51 | 800 | 18.1 |
| 33436 | 24000 | 2.00 | 6.75 | 2.89 | 1.25 | 2.96 | 9.27 | 1 3/4″-5 | 3.75 | 0.40 | 3.51 | 800 | 20.2 |
| 33438 | 24000 | 2.00 | 6.75 | 2.89 | 1.25 | 2.96 | 9.27 | 1 3/4″-8 | 3.75 | 0.40 | 3.51 | 800 | 20.2 |
| 33427 | 30000 | 2.00 | 6.75 | 2.89 | 1.25 | 2.96 | 9.22 | 2″-4 1/2 | 3.75 | 0.40 | 3.51 | 1100 | 22.9 |
| 33432 | 30000 | 2.00 | 6.75 | 2.89 | 1.25 | 2.96 | 9.22 | 2″-8 | 3.75 | 0.40 | 3.51 | 1100 | 22.9 |
| NEW ITEMS | |||||||||||||
| 33501 | 55000 | 2.75 | 9.25 | 3.96 | 1.75 | 4 | 12.86 | 2-1/2-8 | 5.16 | 0.58 | 4.9 | 2400 | 50.4 |
| 33503 | 55000 | 2.75 | 9.25 | 3.96 | 1.75 | 4 | 12.86 | 2-1/2-4 | 5.16 | 0.58 | 4.9 | 2400 | 50.4 |
| 33590 | 55000 | 2.75 | 9.25 | 3.96 | 1.75 | 4 | 12.86 | 2-1/2-8 | 5.16 | 0.58 | 4.47 | 56 | 57.2 |
| 33592 | 55000 | 2.75 | 9.25 | 3.96 | 1.75 | 4 | 12.86 | 2-1/2-4 | 5.16 | 0.58 | 4.47 | 56 | 57.2 |
